Modélisation de la distribution granulométrique des gouttes de Pluie par la loi gamma généralisée

http://dx.doi.org/10.46411/jpsoaphys.2020.02.21

Section  de la parution:  Informations de publication

J. P. Soaphys, Vol 2, N°2 (2021) C20A21

Pages :  C20A21-1  à C20A21-

DOI du journal   : https://doi.org/10.46411/jpsoaphys.journal
DOI du Numéro : https://doi.org/10.46411/jpsoaphys.journal.v2.1
DOI de l’article  : http://dx.doi.org/10.46411/jpsoaphys.2020.02.21
Print ISSN: 2630-0958
Historique de la version : actuelle

Informations sur les auteurs

 Kougbeagbede Hilaire  1, , Moumouni Sounmaïla2, Adjikpe Loïc S. 1 Adechinan Joseph A.3 , Houngninou Etienne B. 1


1 1Laboratoire de Physique de l’Atmosphère, Université d’Abomey-Calavi, Bénin

2 Ecole Normale Supérieure de Natitingou, Université Nationale des Sciences, Technologies, Ingénierie et Mathématiques, Bénin

3 Faculté des Sciences et Techniques de Natitingou, Université Nationale des Sciences, Technologies, Ingénierie et Mathématiques, Bénin

Corresponding author e-mail: hilaire.kougbeagbede[at]fast.uac.bj

RESUME

La distribution granulométrique de la taille des gouttes de pluie joue un rôle crucial dans l’étude de la microphysique des précipitations, l’érosion des sols et la télécommunication. Elle est souvent modélisée par les lois exponentielle, lognormale, gamma standard ou gamma généralisé. Jusqu’à présent en Afrique de l’ouest, la distribution granulométrique de la taille des gouttes de pluie est modélisée par la loi gamma ou lognormale. La présente étude s’est intéressée à la modélisation de la distribution par la loi gamma généralisée normalisée par un double moment. Les données exploitées sont les spectres de gouttes de pluie de durée une minute de la ligne de grain du 25/07/2006. Elles ont été recueillies au cours de la campagne AMMA à Djougou (Nord-Ouest du Bénin) en 2006. Les résultats obtenus montrent que la loi gamma généralisée normalisée par un double moment estime mieux les moments que la loi gamma standard normalisée par un double moment proposé par Moumouni et al., 2008.

Mots-Clés : DSD, pluie, Gamma généralisée, microphysique, AMMA

Ajayi, G. O., and Olsen, R. L., 1985, Modeling of a tropical raindrop size distribution for microwave and millimeter wave applications, Radio Sci., 20(2), 193-202,

Angulo-Martínez, M.; Beguería, S.; Kyselý, J., 2016. ‘’Use of disdrometer data to evaluate the relationship of rainfall kinetic energy and intensity (KE-I)’’, Sci. Total Environ., 568, 83–94.

Depraetere, C., Gosset, M., Ploix, S., Laurent, H., 2008. The organization and kinematics of tropical rainfall systems ground tracked at mesoscale with gages: First results from the campaigns 1999–2006 on the Upper Oueme Valley (Benin). ´ J. Hydrol. 375, 143–160

Feingold, G., and Z. Levin, 1986, The Lognormal Fit to Raindrop Spectra from Frontal Convective Clouds in Israel. J. Climate Appl. Meteor., 25, 1346–1363, .
Lee, G. W., Zawadzki, I., Szymer, W., Sempere-Torres, D., Uijlenhoet, R., 2004, A general approach to double-moment normalization of drop size distribution, J. Appl. Meteor., 43, 264-281
Markowitz, A., 1976, Raindrop Size Distribution Expressions. Journal of Applied Meteorology (1962- 1982), 15(9), pp. 1029-1031
Marshall, J.S., and Palmer, W.M.K., 1948, The Distribution of Raindrops with Size. Journal of Meteorology, 5, 165-166.
Maur, A. N. A., 2001, Statistical Tools for Drop Size Distributions: Moments and Generalized Gamma. J. Atmos. Sci., 58, 407–418,
Moumouni, S., Gosset, M., Houngninou, E., 2008, Main features of rain drop size distributions observed in Benin, West Africa, with optical disdrometers, Geophys. Res. Lett., 35, L23807.
Nanko, K., Moskalski, S. M., Torres, R., 2016. Rainfall erosivity–intensity relationships for normal rainfall events and a tropical cyclone on the US southeast coast, Journal of Hydrology, 534, 440-450.
Nzeukou, A., Sauvageot, H., Ochou, A., Kebe, C., 2004, Raindrop Size Distribution and Radar Parameters at Cape Verde. Journal of Applied Meteorology (1988-2005), 43(1), 90-105
Ochou, A. D., Nzekou, A., Sauvageot, H., 2007, Parameterization of drop size distribution with rain rate, Atmos. Res., 84, 58 – 66
Omotosho, J.B. 1985, The separate contributions of squall lines, thunderstorms and the monsoon to the total rainfall in Nigeria. Journal of Climatology 5, 543–552
Raupach, T. H., and Berne, A., 2017, Invariance of the Double-Moment Normalized Raindrop Size Distribution through 3D Spatial Displacement in Stratiform Rain. J. Appl. Meteor. Climatol., 56, 1663–1680.
Redelsperger, J., Thorncroft, C. D., Diedhiou, C. D., Lebel, T., Parker, D. J., and Polcher, J., 2006,
African Monsoon Multidisciplinary Analysis: An International Research Project and Field Campaign. Bull. Amer. Meteor. Soc., 87, 1739–1746.
Rosenfeld, D., and Ulbrich, C. W., 2003, Cloud Microphysical Properties, Processes, and Rainfall Estimation Opportunities. Meteor. Monogr., 52, 237-258.
Rosewell, C. J., 1986, Rainfall kinetic energy in eastern Australia, J. Climate Appl. Meteor. 25(11): 1695-1701.
Sauvageot, H., and J. Lacaux, 1995, The Shape of Averaged Drop Size Distributions, J. Atmos. Sci., 52, 1070 -1083.
Sekhon, R. S., and Srivastava, R. C., 1971, Doppler Radar Observations of Drop-Size Distributions in a Thunderstorm, J. Atmos. Sci., 28, 983-994.
Sempere-Torres, D., Porrà, J. M., and Creutin, J.D., 1994, A general formulation for raindrop size distribution, J. Appl. Meteor., 33, 1494-1502.
Sempere-Torres, D., Sànchez-Diezma, R., Zawadzki, I., and Creutin, J-D. 1999 , DSD identication following a pre-classication of rainfall type from radar analysis, Preprints, 29th conf on Radar Meteorology, Montreal, QC, Canada, Amer. Meteor. Soc., 632-635.
Sempere-Torres, D., Sànchez-Diezma, R., Zawadzki, I., and Creutin, J-D., 2000, Identiction of stratiform and convective areas using radar data with application to the improvement of DSD analysis and Z-R relations, Phys. Chem. Earth, 25, 985-990.
Testud, J., Oury, s., Black,R. A., Amayenc, P., Dou, X., 2001, The Concept of “Normalized” Distribution to Describe Raindrop Spectra: A Tool for Cloud Physics and Cloud Remote Sensing, J. Appl. Meteor., 40, 1118-1140.
Thurai, M., and Bringi, V. N., 2018, Application of the Generalized Gamma Model to Represent the Full Rain Drop Size Distribution Spectra. J. Appl. Meteor. Climatol., 57.
Uijlenhoet, R., and Stricker, J. N. M., 1999, A consistent rainfall parameterization based on the exponential raindrop size distribution. Journal of Hydrology, 218, 101-127.
Ulbrich, C. W., 1983, Natural variations in the analytical form of the raindrop size distribution. J. Climate Appl. Meteor., 22, 1764-1775.
Waldvogel, A., 1974, The N0 Jump in Raindrop Spectra, Journal of the Atmospheric Sciences, 31, 1067-1078.
